Screw Landing Valve
●Body Material：Copper Alloy
●Handwheel Material：Cast Iron
● Inlet Size：2.5” BSP
●Outlet:2.5” BS 336
●Working pressure:16bar
●Seat Test：16.5bar（239.5psi）
●Body Test： 22.5bar（326.2psi）
● Water flow rate：8.5L/S@4Bar outlet pressure
●OEM Service：Accepted
●Delivery Terms：FOB, CFR, CIF, EXW
●Payment Mode：T/T, L/C, PayPal, Western Union
Product category:
Enterprise Atlas:
Product Details
———
Product Formation
Oblique Landing Valve is a type of globe pattern hydrant valve. These oblique type landing valves are available with flanged inlet or screwed inlet and are manufactured to comply to BS 5041 Part 1 standard with delivery hose connection and blank cap complying with BS 336:2010 standard. The landing valves are classified under low pressure and are suitable for use at nominal inlet pressure up to 15 bars. The internal casting finishes of every valve is of high quality ensuring a low flow restriction that meets the standard’s water flow test requirement.
Oblique type landing valves are suitable for both on-shore and off-shore fire protection applications and suitable for installation on wet risers for firefighting. These valves are generally used with permanently charged water from a pressurized supply with water and accordingly mounted in fire hydrant systems at Internal or External places.
EY WORDS：Screw Landing Valve, Threaded Landing Valve, Fire Hydrant Landing Valve, BSP Thread, NPT Thread, DN15-DN50, Ductile Iron Body, EPDM Seal, Low Pressure Valve, China, manufacturers, suppliers, wholesale, factory.
Other Classifed Products：
Fire Hose Categories, Fire Sprinkler System, Fire Protection Valve , Fire Hose Reel&Cabinet , Fire Foam Equipment，Fire Nozzle and Fire Monitor , Fire Hydrant , UL/FM Fire Fighting Equipment , Brass Valve Categories , Fire Extinguisher Series
———
Product Features
1.Screw Connection Design: Easy to install/disassemble without complex tools, ideal for space-limited areas (e.g., pipe shafts).
2. Reliable Sealing Performance: Prevents water leakage under standard fire system pressure (1.6-2.5MPa), ensuring stable water supply.
3. Durable Material: Made of brass or ductile iron, corrosion-resistant for indoor/outdoor harsh environments.
4. Wide Compatibility: Fits standard fire hydrant systems, compatible with BSP threaded pipes/hoses.
5. Quick Operation: Ergonomic handwheel enables fast on/off, suitable for emergency firefighting.
———
Product Parameter
| Item | Details |
| Type | Screw Connection Landing Valve |
| Installation Method | Landing Valve |
| Body Material | Ductile Iron or Brass |
| Nominal Diameter (DN) | 1/2″–2″ |
| Working Pressure | 0.6–1.6 MPa (6–16 bar) |
| Test Pressure | - Strength Test: 1.5 times the working pressure (sustain for 1 minute, no deformation or leakage); - Seal Test: 1.1 times the working pressure (no visible leakage, compliant with EN 12101-1); |
| Operation Method | Manual Rotation Handle |
———
Processing Steps
Drawing-Mold-Casting-CNC Maching-Assembly-testing-Quality Inspection-Packing
———
