Grooved Indicating Butterfly Valve

Grooved Indicating Butterfly Valve adopts ductile iron or cast iron as its main body material and utilizes grooved connection (no flange welding required, enabling quick pipeline connection via grooved clamps). It features a core visual opening - closing indication device (such as a dial, pointer, or color marker on the top of the valve stem) to intuitively show the “open/closed” status of the valve. The valve plates are mostly made of stainless steel for corrosion resistance, and the sealing surfaces employ EPDM/NBR rubber (for soft sealing) or metal sealing. Its common diameter range is DN50–DN300, pressure ratings are mostly PN1.0–PN2.5, and the applicable medium temperature ranges from - 10 °C to 120 °C, making it suitable for water, fire - fighting water, neutral industrial fluids, etc.
• Applicable medium:Water
• Port size:DN40-DN300
• Structure:Butterfly
• Temperature of media:Low Temperature, Normal Temperature
• Application:General
• Customized support:OEM, ODM
• Power:Manual
• Model number:DN40-DN300
• Color:Customized Color
• OEM:YES
• Working Temperature:-45 to 200 Celsius
• Bushing：PTFE,Nylon,Lubricated Bronze
• Body /Disc：cast iron carbon steel Stainless coppersteel

Product category:

Fire butterfly valve

Email:

linhaifeng117@gmail.com

Inquiry Now

Product Details

———

Production Description

The grooved indicating butterfly valve is a highly efficient isolation and regulation valve, specially designed for pipeline systems requiring quick installation and visual status monitoring. It is widely used in municipal water supply and drainage, fire water supply, HVAC, industrial circulating water, and other fields. Compared with traditional flanged butterfly valves, its grooved connection can significantly reduce installation time (with no drilling or welding required), and the integrated opening - closing indication device can provide real - time feedback on the valve status, thus avoiding pipeline failures caused by "misoperation" or "unclear status". It is especially suitable for scenarios with requirements for installation efficiency and operation monitoring (such as fire emergency pipelines and water supply and drainage systems in large buildings).

———

Product Feature

Quick installation, time-saving & labor-saving: Grooved connection is fastened via clamps, no flange welding or bolt alignment needed. Installation efficiency is >50% higher than traditional flanged valves; later disassembly and maintenance are also easier.
Visible status, controllable safety: Comes with clear open-close indicators (pointer/scale/color mark), enabling judgment of valve on-off status without disassembly, lowering misoperation risk, and suitable for pipelines needing regular inspection.
Efficient flow, reliable sealing: Butterfly valve structure enables 90° rotation for quick on-off, with low full-bore flow resistance (smooth medium flow). Soft (rubber) or metal seal design ensures low leakage, suitable for low-medium pressure clean media.
Durable, corrosion-resistant, wide adaptability: Ductile iron valve body offers high strength and impact resistance. Valve plate/seal is water & weak corrosion-resistant, suitable for long-term use in municipal, fire protection, industrial pipelines and other scenarios.

———

Product Parameter

Applicable medium	Water
Port size	DN40-DN300
Structure	Butterfly
Temperature of media	Low Temperature, Normal Temperature
Application	General
Customized support	OEM, ODM
Power	Manual
Model number	DN40-DN300
Color	Customized Color
OEM	YES
Working Temperature	-45°C to 200 °C
Bushing	PTFE,Nylon,Lubricated Bronze
Body /Disc	cast iron carbon steel Stainless coppersteel

———

FAQ

Q:What is the minimum order quantity for gate valves?

A:The minimum order quantity is 20 units for standard sizes. Production lead time is typically 15-20 working days for standard products. Customized requirements may affect both MOQ and delivery schedule.

Q: What are the available delivery terms?

A:We provide EXW, FOB, CIF, and DAP delivery terms. Our experienced logistics team will recommend the most suitable shipping solution based on your location and specific requirements.

Q: Why choose us?

A:Boasting over 15 years of profound experience in the fire protection industry, our company prides itself on a team of professional technical experts and has established stable cooperative relationships with numerous well-known enterprises in the domestic market. We are committed to providing customers with competitive pricing while strictly guaranteeing product quality, and our capabilities have been fully recognized through multiple authoritative certifications.

——

With more than 15 years of experience serving clients, we have developed extensive expertise and in-depth industry knowledge, enabling us to deliver reliable and effective solutions tailored to your requirements.
We provide professional technical support and customized service offerings. Our committed technical team is available to assist you with product consultation, installation guidance, and comprehensive after-sales support whenever necessary.
At Sheng Feng Fire, our professionals are dedicated to helping you select the most suitable products based on your specific needs.
Please do not hesitate to contact us for further information！
