ESFR Fire Sprinkler 74degree
•Material :brass/304 stainless steel frame
•Size :3/4"-1-1/4" BSP thread
•Nominal Pressure :0.35 - 0.70 MPa（51 - 102 psi）
•Operating Temp:'-40℃to +74℃
•OEM Service：Accepted
•Delivery Terms：FOB, CFR, CIF, EXW
•Payment Mode：T/T, L/C, PayPal, Western Union
Product category:
Product Details
74 Degree ESFR Fire Sprinkler
ESFR (Early Suppression, Fast Response) fire sprinkler systems are advanced sprinkler systems designed to provide rapid and effective fire suppression in high-hazard environments such as warehouses, distribution centers, and other large storage spaces.
ESFR sprinklers are specifically engineered to provide early suppression of fires by releasing a large volume of water in a short period of time. They typically have larger orifices and higher water flow rates compared to standard sprinklers. The distinguishing feature of ESFR sprinklers is their ability to discharge water directly towards the fire, creating a strong, concentrated spray pattern that can effectively penetrate the fire plume and suppress the flames.
ESFR sprinklers are typically ceiling-mounted and are designed to be installed at specific maximum distances from storage racks or other obstructions. They operate at higher pressure levels, usually between 50 psi (pounds per square inch) and 175 psi, allowing for greater water delivery and coverage.
Advantages:
1.Cold and frost resistant due to the fusible alloy.
2.High pressure resistant and durable.
3.Quick response and higher fire extinguisher effect. K=16.8
Specifications
(1 ) Nominal caliber: 20mm, connection thread: R3 / 4 "or NPT3 / 4", water supply branch ≥ DN50.
( 2 ) Flow characteristic coefficient : K = 242 or K=14.2.
(3 ) Response time index (RTI) is 28 ±8m ·s ~ (-1) ~ (0.5).
(4 ) Maximum working pressure: 1.2 MPA.
(5 ) 100% Ex-factory pressure test: 3.45MPA
(6 )Nominal action temperature: 68 ℃.
(7 )Maximum coverage area: 9.3 mm, maximum spacing: 3.05m.
Installation, Usage, and Maintenance:
During installation, should pay attention not to damage the bulb to avoid affect the thermal performance. In the process of wrench and twist, do not use spanner to wrench the supporting arm to deformation and affect the sealing performance (note: the bulb temperature can be chosen according to the needs of users)
Application:
It is usually installed in areas with fire danger, including warehouses, shopping malls, hotels, hospitals, theaters, office building, high-rise building, garages and etc.
Related product to 74 degree centigrade K14.2 ESFR fire sprinkler
More fire sprinkler product selection
Features
The Early Suppression Fast Response 74°C Fire Sprinkler is a specialized fire protection device meticulously engineered for high-hazard warehousing and high-stack storage environments. It delivers rapid fire suppression in the initial stages and prevents flames from penetrating deep into storage stacks through a synergistic combination of "fast response, high flow rate, and precise coverage." Its core attributes are centered around three key aspects: ESFR technology positioning, 74°C activation temperature suitability, and reliability in demanding warehouse conditions, elaborated as follows:
1. ESFR Technology Positioning: Early Suppression, Rapid Fire Control;
2. 74°C Activation Temperature: Suited for Medium-High Temperature Smoldering Scenarios;
3. High Flow Rate and Coverage Capability: The Core Guarantee for Penetrating High Stacks;
4. Materials and Durability: Adaptation to Harsh Warehousing Environments;
Product Parameter
| Material : | brass/304 stainless steel frame |
| Size : | 3/4"-1-1/4" BSP thread |
| Nominal Pressure : | 0.35 - 0.70 MPa（51 - 102 psi） |
| Channel Design : | Full Port Straight Through Type |
| Working Media : | water |
| Operating Temp : | -40℃to +74℃ |
FAQ
Q: Can you accept sample order?
A: Yes, we accept samples with little and reasonablecharge.But need customer pay sample fees and transportfees firest.
Q: What is your payment terms?
A: Payment supports T/T, L/C, etc.
Q: How can l get my order?
A: We will send you the goods by UPS,DHL,Fedex,OverseaShipment or other forwarder, all with tracking number.
Q: Why choose us?
A; With over 10 years of experience in the fire protectionindustry, our company has professional technical personne!and many well-known partners in the domestic market. Weoffer favorable prices and guarantee quality, having passedmultiple certifications!
——
We serve customers for over 10 years — so we’ve got the knowledge and industry experience to help you get it right.Professional technical support, intimate service experience We have a professional technical support team, at any time to provide you with product consultation, installation guidance and after-sales service.
Let the professionals at Sheng Feng Fire help you select the products that meet your exact needs.
Welcome to inqury us！
KEY WORDS： ESFR fire sprinkler，fire sprinkler head，1inch fire sprinkler
