79 Degree Standard Sidewall Fire Sprinkler
Product category:
Product Details
Sidewall Standard Fire Sprinkler
Sidewall fire sprinklers install along walls or beneath beams where ceiling piping is unavailable, or where aesthetic concerns or obstructions weigh against the use of other sprinkler types. Most are designed to protect small rooms, closets, or hallways and have a semicircular deflector that produces a crescent-shaped spray pattern. Horizontal sidewall sprinklers should only be installed below smooth, flat, They are used in hotels, restaurants, churches, and a range of commercial structures, and most sidewall fire sprinklers utilize a 1/2″ (12.7 mm) thread connection and feature a 5.6 K-factor.
KEY WORDS： Standard fire sprinkler，sidewall sprinkler head，glass bulb sprinkler，China, manufacturers, suppliers, wholesale, factory
Other Classified Products： Fire Hose Series，Fire Hydrant Valve，Fire Valve Series，Fire Hose Reel Cabinet，Fire Hose Nozzle System，Fire Coupling，Fire Water Monitor
Specification
| Model | Installation form | Diameter | Connecting Thread (inch) | K-factor | Temperature |
| T-ZSTX15 | Sidewall | DN15 | R 1/2 | K 5.6,K 8.0 | 57℃，68℃，79℃，93℃，141℃ |
| T-ZSTX20 | Sidewall | DN20 | R 3/4 | K 5.6,K 8.0 | 57℃，68℃，79℃，93℃，141℃ |
More fire sprinkler product selection
Features
Features can be summarized as "sidewall adaptability, low-temperature sensitivity, precise coverage, and multi-scenario protection," specifically designed for ceiling-less spaces or scenarios requiring sidewall protection. Through the synergy of low activation temperature and sidewall installation, it achieves earlier fire suppression and efficient protection. Details are as follows:
1.Installation Method: Sidewall mounting for precise coverage of wall areas.
2.Temperature Sensing Performance: Low-temperature sensitivity enables earlier fire suppression activation.
3.Water Spray Characteristics: Sidewall coverage suits low-hazard scenarios.
4.Material and Durability: Adaptability to multiple environments ensures long-term operational stability.
5.Scenario Adaptability: Addresses low-hazard protection needs in ceiling-less or sidewall-protected spaces.
Product Parameter
| Material : | 57-3 brass or 304 stainless steel |
| Size : | 1/2" or 3/4" BSPT |
| Nominal Pressure : | 1.0-2.0 MPa（10-20 bar） |
| Channel Design : | Full Port Straight Through Type |
| Working Media : | Water |
| Operating Temp : | 79°C（±3°C） |
FAQ
Q: Can you accept sample order?
A: Yes, we accept samples with little and reasonablecharge.But need customer pay sample fees and transportfees firest.
Q: What is your payment terms?
A: Payment supports T/T, L/C, etc.
Q: How can l get my order?
A: We will send you the goods by UPS,DHL,Fedex,OverseaShipment or other forwarder, all with tracking number.
Q: Why choose us?
A; With over 15 years of experience in the fire protectionindustry, our company has professional technical personne!and many well-known partners in the domestic market. Weoffer favorable prices and guarantee quality, having passedmultiple certifications!
——
With more than 15 years of experience serving clients, we have developed extensive expertise and in-depth industry knowledge, enabling us to deliver reliable and effective solutions tailored to your requirements.
We provide professional technical support and customized service offerings. Our committed technical team is available to assist you with product consultation, installation guidance, and comprehensive after-sales support whenever necessary.
At Sheng Feng Fire, our professionals are dedicated to helping you select the most suitable products based on your specific needs.
